Automatic Vegetable Chips Vacuum Frying Machine is used for fruits and vegetable low-temperature frying, which can avoid color-changing or fragrance loss during frying. Vegetable Chips Vacuum Frying Machine can also avoid oil deterioration which can save a lot of oil. With the advanced technology of vacuum frying, fresh fruits or vegetables can become Fruit and vegetable chips in a very short time. These Vegetable Chips or Fruit Chips is low moisture content and low oil content, which is easy to keep and looks very good. Nowadays, Low-Temperature Vacuum Frying Machine has been widely used for fruit (apple, banana, jackfruit, pineapple, peach etc.), vegetables (carrot, pumpkin, snap bean, sweet potato, taro, garlic, green pepper, onion …..), dry fruits, Chinese date, peanut, and other aquatic products and meats.
Features of Low-Temperature Vacuum Frying Machine
- The vacuum frying process include heating, frying, oil storage, deoiling, dewatering, oil filter integration design, which is under vacuum condition. Because of lack of oxygen in food processing, this can reduce or even avoid oxidation (such as fatty acids, enzymatic Browning and other oxidation, etc.) caused by the damage. In the negative pressure state, the water (free water and partially combined water) inside the food will rapidly evaporate and spurt out with oil as the heat transfer medium, causing the tissue to form a loose and porous structure.
- Automatic control of temperature and pressure (vacuum degree), no overheating, no overpressure, to ensure product quality and safe production.
- Variable Frequency Regulation is adopted for oil removal, which is suitable for all products with low oil content and high oil content.
- The oil-water separation system can cool and separate the evaporated water and oil, reduce the pollution of water circulation, improve the repeated utilization rate of water and reduce the loss of oil.
- Oil filtration system: upper and lower oil tanks, two-chamber heating system, separate control of heating, oil circulation filtration during frying, so that the oil is always kept clean, and reduce oil waste.
- The machine is made of the national standard food-grade non-rust rigid material, featuring high efficiency, stable performance and convenient installation and use.
Parts List of Vacuum Frying Machine
Item | Name | Quantity | Remark | |
| 1 | Vacuum frying tank | 1 | set | SUS304(GB) |
| 2 | Oil tank | 1 | set | SUS304(GB) |
| 3 | oil circulating pump | 1 | pcs | SUS304(GB) |
| 4 | Condenser (high performance) | 1 | group | The Dutch technology |
| 5 | External heater (high performance) | 1 | group | The Dutch technology |
| 6 | Oil and water separator assembly | 1 | set | Independent research and development |
| 7 | Circulating filter | 1 | pcs | SUS304(GB) |
| 8 | Vacuum pump roots assembly | 1 | group | SUS304 |
| 9 | Vacuum pipeline and circulating oil pipeline fittings | 1 | set | Sus304food grade |
| 10 | pneumatic ball valve | 1 | pcs | Sus304food grade |
| 11 | manual butterfly valve | 1 | pcs | Sus304food grade |
| 12 | Manual butterfly valve | 1 | pcs | Sus304food grade |
| 13 | Manual butterfly valve | 2 | pcs | Sus304food grade |
| 14 | PT100 | 2 | pcs | GB |
| 15 | Bottom rotating mechanism (lianxing patented product) | 1 | group | German mechanical seal ring |
| 16 | basket | 2 | pcs | SUS304(Gb punching) |
| 17 | Liquid level sight glass | 4 | pcs | |
| 18 | searchlight | 2 | pcs | |
| 19 | Emptying valve | 4 | pcs | |
| 20 | Pneumatic Angle seat valve | 3 | pcs | |
| 21 | Stainless steel frame bracket | 1 | set | SUS304(GB) |
| 22 | electrical control cabinet | 1 | set | |
| 23 | Discharging device | 1 | set | |
| 24 | operating deck | 1 | set | |
| 25 | Equipment instruction and after-sales service card | 1 | pcs | |
| 26 | Installation Instruction | 1 | pcs | |
Working Video of Low-Temperature Vacuum Frying Machine
