Vegetable Peeling Machine

Automatic Small Onion Peeling Machine

Small Size Onion Peeling Machine is special design for small size onion which diameter is small than 40mm.  It adopt special feeding method, which can peel 300kg-500kg per hour fo ...
Product Details

Automatic-Pneumatic-Small-Onion-Peeling-Machine

Small Size Onion Peeling Machine is special design for small size onion which diameter is small than 40mm.  It adopt special feeding method, which can peel 300kg-500kg per hour for small red onion. For such a small micro onion peeling, it need to use a special way, we have developed this specifically for small and micro onion peeling machine, using flexible leather agencies, only the small onion skin pierced without will hurt the inner layer, it is easy to remove and clean the onion skin.

Advantages Features of Small Onion Peeling Machine

  1. This peeling machine uses automatic mechanized operations, not simply peeling an onion into the hopper, conveyor machine can be transported to the onion peeling of the skin and body, the device will be fully automatic skinning.
  2. This peeling machine suitable for different type onion skin peeling,  regardless of onion skin thickness and tight . This peeling machine can  realize one-time clean.
  3. Special design of the aircraft skin ways to make sure no damage to onion after peeling.



Specification of Small Diameter Onion Peeling Machine

ModelRM-SOP40
Capacity40raw/min(for 30mm onion, each raw can contain 12pcs, means 480pcs/min for 30mm onion)

(for 50mm onion, each raw can contain 7pcs, it means 280pcs/min for 50m onion)

Voltage380V 50Hz  3phase(customized available)
Power1.5KW
DimensionL*W*H=2.56*0.95*1.82m
Compressed AirCompressed Air Pressure:0.8-1.0MPa,Air Volume:6-8m3



Working Video of Small Size Onion Peeling Machine

Company Profile

Adhering to the principle of managing scientifically and honesty and credit, our factory has passed ISO9001-2000 quality system certification. Now, Our factory can provide onion dry cleaning machineonion water washing machineonion mesh bag packing machineonion peeling machineonion root cutting machineonion cutting machineonion dryer machineonion powder production lineonion powder bottle filling sealing machine.

Our onion processing products have passed with CE, ISO and SGS Certificates and has been widely sold all over the world.
